Ultra-compact, high-performance WiFi 6 router for industrial mobility
 |
 |
 |
 |
| APPLICATIONS AGVs, AMRs, Robots… Industrial automation Remote access | |||
| Ethernet interface | 1-port 2.5 Gigabit Ethernet Base TX auto-sensing, auto MDI/MDIX cross-over (10/100/1000/2500), RJ45 Ethernet interface | ||||||||||
| WiFi interface | 2 concurrent radios WiFi6 (IEEE 802.11 ax) 2.4 GHz and 5 GHz, MIMO 2T2R, ANI (Adaptive Noise Immunity) | ||||||||||
| WiFi radio data rate | 1201Mbps @ 5GHz, 573.5 Mbps @ 2.4GHz | ||||||||||
| Operating frequencies | ISM : 2.4-2.483 GHz (up to 14 channels) UNII : 5.15-5.25 GHz (up to 4 channels) UNII-2 : 5.25-5.35 GHz (up to 4 channels) UNII-2 ext : 5.470-5.725 GHz (up to 11 channels) UNII-3 : 5.725-5.825 GHz (up to 4 channels) Supports DFS and TPC |
||||||||||
| Output power | 2.4 GHz: up to 25 dBm (aggregate) / 5 GHz : up to 23 dBm (aggregate) | ||||||||||
| Sensitivity max. | 2.4 GHz : -83 dBm / 5 GHz : -91 dBm | ||||||||||
| Radio connectors | 2 x RP-SMA | ||||||||||
| Security | EN 18031 with firewall, CRA, DoS, https, MAC filtering, WPA/WPA2/WPA3-Personal & Enterprise (IEEE 802.1X/RADIUS), tunnels L2 (GRE), VPN (OpenVPN, IPsec), SNMP V3, Rogue AP detector, Secure BOOT | ||||||||||
| WiFi modes | Access point, client, router, Rogue AP detector, advanced mesh (optional) | ||||||||||
| WiFi services | Fast roaming, hot Spot 2.0, Wireless Load Balancing (Load balancing, band steering, client roaming control), WMM QoS | ||||||||||
| Ethernet networking | IPv4/IPv6 compliance, frames filtering, bridging, repeater, STP/RSTP, VLAN, DHCP (server & client), DNS relay | ||||||||||
| Ethernet routing | Multicast (PIM), IP redundancy (VRRP), static routes, NAT 1:1, NAT router, router | ||||||||||
| Administration | http, https, MQTT, SNMP agent (V1, V2C, V3), CLI Micro-SD card : save/ restore configuration and logs storage WaveManager On premise or Cloud administration tool |
||||||||||
| LEDs Signaling | Radio : status | Ethernet : status – activity | Power : on-off | SD card status | ||||||||||
| Power supply | +9VDC to +48VDC, 3-pin Phoenix connector & PoE 802.3af | ||||||||||
| Consumption | IDLE mode: 4 W/ Maximum average: 10 W / Recommended power supply: 15 W | ||||||||||
| Dimensions & weight | Compact case L : 105 x l : 79 x h : 30 mm without DIN rail or mounting plate, 236g | ||||||||||
| Standards and certifications |
|
||||||||||
| Environment | IP30 Operating temperature: -0°C to +65°C , storage: -40°C à +85°C, humidity: 0% to 99% (non-condensing) |
||||||||||
| MTBF | TBD | ||||||||||
| Warranty | 5 years |
| AirWave | Compact all-in-one industrial WiFi 11ax router (client, access point, repeater, router + optional advanced mesh), concurrent dual radios 2.4 GHz and 5 Ghz, one 2.5 GbE port. Delivered with antennas. |
| Optional accessories : | |
| PWS12-UNI-PH3 WL-FIX-RD2 WL-PLT-2 SOCLE-RPS/RPS-1.5M |
AC (110V / 220V) to 12VDC power adapter with cable terminated by a 3-pin Phoenix terminal block Din rail fixing kit Mounting plate Magnetic base for RP-SMA antenna 1.5m cable (RP-SMA plug) |
| Optional Software |
|
| WaveManager (NMS) | Lifetime on-premise licence |
4.6.2.1 – 1.6.0.1 – – 1.0.3.1 Version Download WaveManager : Deployment & centralized management software for WaveOS-based WiFi products, Windows and Linux platforms
